18 Introduction to the manual
Operation principle and hardware description describes the drive module.
Planning the cabinet installation guides in planning drive cabinets and installing the drive
module into a user-defined cabinet. The chapter gives cabinet layout examples and free
space requirements around the module for cooling.
Mechanical installation describes how to install the basic drive module into a cabinet.
Planning the electrical installation instructs in the motor and cable selection, protections
and cable routing.
Electrical installation instructs in how to wire the drive.
Installation checklist contains lists for checking the mechanical and electrical installation of
the drive.
Start-up describes the start-up procedure of the drive.
Fault tracing describes the fault tracing of the drive.
Maintenance contains preventive maintenance instructions.
Technical data contains the technical specifications of the drive module eg, the ratings,
sizes and technical requirements, provisions for fulfilling the requirements for CE and
other markings.
Dimension drawings contains dimension drawings of the drive modules and auxiliary
components.
Example circuit diagrams shows an example circuit diagram for a cabinet-installed drive
module.
du/dt filters and sine filters describes how to select du/dt filters for the drive.
Related manuals
See List of related manuals on the inside of the front cover.
Categorization by option code
The instructions and technical data which concern only certain optional selections are
marked with option codes eg, +0C168. The options included in the drive can be identified
from the option codes visible on the type designation label. The option selections are listed
in section Type designation key on page 29.
Quick installation, commissioning and operating
flowchart
Task See
Plan the electrical installation.
Check the ambient conditions, ratings, required cooling
air flow, input power connection, compatibility of the
motor, motor connection, and other technical data.
Select the cables.
Planning the cabinet installation (page 31)
Planning the electrical installation (page 51)
Technical data (page 105)
Option manual (if optional equipment is included)
