48 ACS 160 User’s Manual
0122 AO 0 - 20 mA 0.1 mA - 22
0124
ACTUAL VALUE 1 0 - 100 % 0.1 % - 24
0125
ACTUAL VALUE 2 0 - 100 % 0.1 % - 25
0126
CONTROL DEV -100 - 100 % 0.1 % - 26
0127
PID ACT VALUE -100 - 100 % 0.1 % 27
0128 LAST FAULT 0 - 26 1 28
0129 PREVIOUS FAULT 0 - 26 1 29
0130
OLDEST FAULT 0 - 26 1 30
0131
SER LINK DATA 1 0 - 255 1 31
0132
SER LINK DATA 2 0 - 255 1 32
0133
SER LINK DATA 3 0 - 255 1 33
0134
PROCESS VAR 1- - 34
0135
PROCESS VAR 2- - 35
0136
RUN TIME 0.00 - 99.99 kh 0.01 kh 36
0137 MWh
COUNTER 0 - 9999 MWh 1 MWh 37
Group 10
COMMAND INPUTS
1001
EXT1 COMMANDS 0 - 10 1 2 / 4 101 üü
1002 EXT2 COMMANDS 0 - 10 1 0 102 üü
1003 DIRECTION 1 - 3 1 3 103 ü ü
Group 11
REFERENCE SELECT
1101
KEYPAD REF SEL 1 - 2 1 1 (REF1 (Hz)) 126
1102
EXT1/EXT2 SEL 1 - 8 1 6 127 üü
1103 EXT REF1 SELECT 0 - 13 1 1 128 üü
1104 EXT REF1 MIN 0 - 250 Hz 1 Hz 0 Hz 129
1105 EXT REF1 MAX 0 - 250 Hz 1 Hz 50 Hz / 60 Hz 130
1106 EXT REF2 SELECT 0 - 13 1 0 131 üü
1107 EXT REF2 MIN 0 - 100 % 1 % 0 % 132
1108
EXT REF2 MAX 0 - 500 % 1 % 100 % 133
1115
REF STEP SEL 0 - 2 1 0 140
1117
REF STEP MODE 0 - 1 1 1 142
1118
REF STEP UP 0 - 250 Hz
0 - 250 %
0.1 Hz
0.1 %
0
0
143
1119
REF STEP DOWN 0 - 250 Hz
0 - 250 %
0.1 Hz
0.1 %
0
0
144
1120
STEP DLY ON 0 - 25.0 s 0.1 s 0 145
1121
STEP DLY OFF 0 - 25.0 s 0.1 s 0 146
Group 12
CONSTANT SPEEDS
1201
CONST SPEED SEL 0 - 10 1 3 / 0 151 üü
1202 CONST SPEED 1 0 - 250 Hz 0.1 Hz 5 Hz 152
1203 CONST SPEED 2 0 - 250 Hz 0.1 Hz 10 Hz 153
Code Name Range Resolution
Default /
US Default
Profibus
par. num
User S M
