ACS 160 User’s Manual 49
1204 CONST SPEED 3 0 - 250 Hz 0.1 Hz 15 Hz 154
1205 CONST SPEED 4 0 - 250 Hz 0.1 Hz 20 Hz 155
1206
CONST SPEED 5 0 - 250 Hz 0.1 Hz 25 Hz 156
1207
CONST SPEED 6 0 - 250 Hz 0.1 Hz 40 Hz 157
1208
CONST SPEED 7 0 - 250 Hz 0.1 Hz 50 Hz 158
Group 13
ANALOGUE INPUTS
1301 MINIMUM AI1 0 - 100 % 1 % 0 % 176
1302 MAXIMUM AI1 0 - 100 % 1 % 100 % 177
1303
FILTER AI1 0 - 10 s 0.1 s 0.1 s 178
1304
MINIMUM AI2 0 - 100 % 1 % 0 % 179
1305
MAXIMUM AI2 0 - 100 % 1 % 100 % 180
1306
FILTER AI2 0 - 10 s 0.1 s 0.1 s 181
Group 14
RELAY OUTPUTS
1401 RELAY OUTPUT 1 0 - 34 1 3 201
1402 RELAY OUTPUT 2 0 - 34 1 2 202 ü
1403 RO 1 ON DELAY 0 - 3600 s 0.1 s; 1 s 0 s 203
1404
RO 1 OFF DELAY 0 - 3600 s 0.1 s; 1 s 0 s 204
1405
RO 2 ON DELAY 0 - 3600 s 0.1 s; 1 s 0 s 205
1406
RO 2 OFF DELAY 0 - 3600 s 0.1 s; 1 s 0 s 206
Group 15
ANALOGUE OUTPUT
1501
AO CONTENT 102 - 137 1 103 226
1502
AO CONTENT MIN 0.0 - 999.9 0.1 0.0 Hz 227
1503 AO CONTENT MAX 0.0 - 999.9 0.1 50.0 Hz / 60.0 Hz 228
1504 MINIMUM AO 0.0 - 20.0 mA 0.1 mA 0 mA 229
1505
MAXIMUM AO 0.0 - 20.0 mA 0.1 mA 20.0 mA 230
1506
FILTER AO 0 - 10 s 0.1 s 0.1 s 231
Group 16
SYSTEM CONTROLS
1601
RUN ENABLE 0 - 6 1 0 251 üü
1602 PARAMETER LOCK 0 - 1 1 1 (OPEN) 252
1604
FAULT RESET SEL 0 - 7 1 6 254 üü
1605 LOCAL LOCK 0 - 1 1 0 (OPEN) 255
1608
DISPLAY ALARMS 0-1 1 0 (NO) 258
Group 20
LIMITS
2003 MAX CURRENT 0.5*I
N
- 1.5*I
N
** 0.1 A 1.5*I
N
** 353
2005 OVERVOLT CTRL 0 - 1 1 1 (ENABLE) 355
2006
UNDERVOLT CTRL 0 - 2 1 1 (ENABLE TIME) 356
2007 MINIMUM FREQ 0 - 250 Hz 1 Hz 0 Hz 357
2008 MAXIMUM FREQ 0 - 250 Hz 1 Hz 50 Hz / 60 Hz 358 ü
Code Name Range Resolution
Default /
US Default
Profibus
par. num
User S M
