50 ACS 160 User’s Manual
Group 21
START/STOP
2101
START FUNCTION 1 - 4 1 1 (RAMP) 376 ü
2102 STOP FUNCTION 1 - 2 1 1 (COAST) 377
2103 TORQ BOOST CURR 0.5*I
N
-
1.5...1.7*I
N
**
0.1 A 1.2*I
N
** 378 ü
2104 STOP DC INJ TIME 0 - 250 s 0.1 s 0 s 379
2105
PREMAGN SEL 0 - 6 1 0 380 üü
2106 PREMAGN MAX TIME 0.0 - 130.0 s 0.1 s 2.0 s 381
2107
START INHIBIT 0 - 1 1 1 (ON) 382
Group 22
ACCEL/DECEL
2201
ACC/DEC 1/2 SEL 0 - 5 1 5 401 üü
2202 ACCELER TIME 1 0.1 - 1800 s 0.1; 1 s 5 s 402
2203 DECELER TIME 1 0.1 - 1800 s 0.1; 1 s 5 s 403
2204 ACCELER TIME 2 0.1 - 1800 s 0.1; 1 s 60 s 404
2205 DECELER TIME 2 0.1 - 1800 s 0.1; 1 s 60 s 405
2206 RAMP SHAPE 0 - 3 1 0 (LINEAR) 406
Group 25
CRITICAL FREQ
2501
CRIT FREQ SEL 0 - 1 1 0 (OFF) 476
2502
CRIT FREQ 1 LO 0 - 250 Hz 1 Hz 0 Hz 477
2503
CRIT FREQ 1 HI 0 - 250 Hz 1 Hz 0 Hz 478
2504
CRIT FREQ 2 LO 0 - 250 Hz 1 Hz 0 Hz 479
2505
CRIT FREQ 2 HI 0 - 250 Hz 1 Hz 0 Hz 480
Group 26
MOTOR CONTROL
2603
IR COMPENSATION 0 - 60 V 1 V 10 V 503
2604
IR COMP RANGE 0 - 250 Hz 1 Hz 50 Hz / 60 Hz 504
2605
LOW NOISE 0 - 1 1 0 (OFF) 505 ü
2606 U/f RATIO 1 - 2 1 1 (LINEAR) 506 ü
2607 SLIP COMP RATIO 0 - 250 % 1 % 0 % 507 ü
Group 30
FAULT FUNCTIONS
3001
AI<MIN FUNCTION 0 - 3 1 1 (FAULT) 601
3002
PANEL LOSS 1 - 3 1 1 (FAULT) 602
3003
EXTERNAL FAULT 0 - 5 1 0 (NOT SEL) 603
3004
MOT THERM PROT 0 - 2 1 1 (FAULT) 604
3005
MOT THERM TIME 256 - 9999 s 1 s 500 s 605
3006
MOT LOAD CURVE 50 - 150 % 1 % 100 % 606
3007
ZERO SPEED LOAD 25 - 150 % 1 % 70 % 607
3008
BREAK POINT 1 - 250 Hz 1 Hz 35 Hz 608
3009
STALL FUNCTION 0 - 2 1 0 (NOT SEL) 609
Code Name Range Resolution
Default /
US Default
Profibus
par. num
User S M
