114 Program features
Maintenance trigger
A maintenance trigger can be activated to show a notice on the panel display when,
for example, drive power consumption has exceeded the defined trigger point.
Settings
Parameter Group 29: Maintenance trig
Acceleration and deceleration ramps
Two user-selectable acceleration and
deceleration ramps are available. It is possible to
adjust the acceleration/deceleration times and
the ramp shape. Switching between the two
ramps can be controlled via a digital input or
fieldbus.
The available ramp shape alternatives are
Linear and S-curve.
Linear: Suitable for drives requiring steady or
slow acceleration/deceleration.
S-curve: Ideal for conveyors carrying fragile loads, or other applications where a
smooth transition is required when changing the speed.
Settings
Parameter Group 22: Accel/Decel
Linear
S-curve
Motor speed
t (s)
2
