316 Fieldbus control
 Loop gains
PRC PID GAIN (Point 50) and PRC PID ITIM (Point 51) are PID parameters similar to
the P and I gains in the APOGEE TECs. Because the ABB PI loop and the Siemens
loop are structured differently, there is no a one-to-one correspondence between the
gains. The following formulas allow translation from ABB gains to Siemens gains and
vice versa:
• To convert from ABB PI gains to Siemens P and I gains:
• To convert from Siemens P and I gains to ABB PI gains:
 Point database
The following table lists the point database for FLN / ACS320 (Application 2762).
FLN Point Database
Point
Subpoint Name
Factory
Default
Engr.
Units
Slope Intercept
On Text Off Text
# Ty pe (SI Units)
01 LAO CTLR
ADDRESS
99 - 1 0 - -
02 LAO APPLICATION 2734 - 1 - -
{03} LAI FREQ OUTPUT 0 Hz 0.1 0 - -
{04} LAI PCT OUTPUT 0 PCT 0.1 0 - -
{05} LAI SPEED 0 RPM 1 0 - -
{06} LAI CURRENT 0 A 0.1 - -
{07} LAI TORQUE 0 PCT 0.1 -200 - -
{08} LAI POWER 0
(0)
HP
(KW)
0.134
0.1
0
0
--
{09} LAI DRIVE TEMP 77
(25)
° F
(° C)
0.18
(0.1)
32
0
--
{10} LAI DRIVE KWH 0 KWH 1 - -
{11} LAI DRIVE MWH 0 MWH 1 - -
{12} LAI RUN TIME 0 HRS 1 - -
{13} LAI DC BUS VOLT 0 V 1 - -
P GAIN
Siemens
= PI GAIN
ABB
x 0.0015
I GAIN
Siemens
=
PI GAIN
ABB
PI GAIN
ABB
x 0.0015
P GAIN
ABB
= PI GAIN
Siemens
x 667
I GAIN
ABB
=
PI GAIN
Siemens
PI GAIN
Siemens
x 667
