ABB ACS320 - Alarm messages generated by the drive

Fault tracing 361
Alarm messages generated by the drive
CODE ALARM CAUSE WHAT TO DO
2001 OVERCURRENT
0308 bit 0
(programmable fault
function 1610)
Output current limit
controller is active.
Check motor load.
Check acceleration time (2202 and
2205).
Check motor and motor cable
(including phasing).
Check ambient conditions. Load
capacity decreases if installation site
ambient temperature exceeds 40 °C.
See section Derating on page 386.
2002 OVERVOLTAGE
0308 bit 1
(programmable fault
function 1610)
DC overvoltage
controller is active.
Check deceleration time (2203 and
2206).
Check input power line for static or
transient overvoltage.
2003 UNDERVOLTAGE
0308 bit 2
(programmable fault
function 1610)
DC undervoltage
controller is active.
Check input power supply.
2004 DIR LOCK
0308 bit 3
Change of direction is
not allowed.
Check the settings of parameter 1003
DIRECTION.
2005 IO COMM
0308 bit 4
(programmable fault
function 3018, 3019)
Fieldbus
communication break
Check status of fieldbus
communication. See chapter
Fieldbus control on page 283.
Check fault function parameter
settings.
Check connections.
Check if master can communicate.
2006 AI1 LOSS
0308 bit 5
(programmable fault
function 3001, 3021)
Analog input AI1 signal
has fallen below limit
defined by parameter
3021 AI1 FAULT
LIMIT.
Check fault function parameter
settings.
Check for proper analog control
signal levels.
Check connections.
2007 AI2 LOSS
0308 bit 6
(programmable fault
function 3001, 3021)
Analog input AI2 signal
has fallen below limit
defined by parameter
3022 AI2 FAULT
LIMIT.
Check fault function parameter
settings.
Check for proper analog control
signal levels.
Check connections.
2008 PANEL LOSS
0308 bit 7
(programmable
fault function 3002)
Control panel selected
as active control
location for drive has
ceased
communicating.
Check panel connection.
Check fault function parameters.
Check control panel connector.
Refit control panel in mounting
platform.
If drive is in external control mode
(REM) and is set to accept start/stop,
direction commands or references via
control panel:
Check Group 10: Start/Stop/Dir and
Group 11: Reference select settings.
