150 Actual signals and parameters
Group 01: Operating data
This group contains drive operating data, including actual signals. The drive sets the
values for actual signals, based on measurements or calculations. You cannot set
these values.
Group 01: Operating data
Code Description Range Resolution Default S
0101
SPEED & DIR
-30000...30000 1 rpm -
The calculated speed of the motor (rpm) & motor direction.
0102
SPEED
0 … 30000 rpm 1 rpm -
The calculated speed of the motor (rpm).
0103
OUTPUT FREQ
0.0 … 500.0 Hz 1Hz -
The frequency (Hz) applied to the motor. (Also shown by default in OUTPUT display.)
0104
CURRENT
0.0 … 1.5*I
2N
0.1 A -
The motor current, as measured by the drive. (Also shown by default in OUTPUT
display.)
0105
TORQUE
-200% … 200% 0.1% -
Output torque. Calculated value of torque on motor shaft in % of motor nominal torque.
0106
POWER
-1.5 … 1.5*P
N
0.1 kW -
The measured motor power in kW.
0107
DC BUS VOLTAGE
0 V … 2.5*V
dN
1V -
The DC bus voltage in VDC, as measured by the drive.
0109
OUTPUT VOLTAGE
0 V … 2.0*V
dN
1V -
The voltage applied to the motor.
0110
DRIVE TEMP
0°C … 150°C1°C-
The temperature of the drive power transistors in Celsius.
0111
EXTERNAL REF 1
0 … 500 Hz 0.1 Hz -
External reference, REF1or Hz.
0112
EXTERNAL REF 2
0% … 100%
(torque: 0% … 600%)
0.1% -
External reference, REF2, in %
0113
CTRL LOCATION
0 … 2 1 -
Active control location. Alternatives are:
0 = HAND
1 = EXT1
2 = EXT2
0114
RUN TIME (R)
0 … 10000 h 1 h 0 h
The drive’s accumulated running time in hours (h).
•Can be reset by pressing UP and DOWN buttons simultaneously when in
parameter set mode.
