124 Program features
 Settings
 Diagnostics
Parameter
Additional information
1101 Local control mode reference type selection
1102 EXT1/2 selection
1106 PID1 activation
1107 REF2 minimum limit
1501 PID2 output (external controller) connection to AO
9902 PID control macro selection
Group 40: Process PID set
1…Group 41: Process PID set 2
PID1 settings
Group 42: Ext / Trim PID PID2 settings
Actual signal
Additional information
0126/0127 PID 1/2 output value
0128/0129 PID 1/2 setpoint value
0130/0131 PID 1/2 feedback value
0132/0133 PID 1/2 deviation
