Fieldbus control 319
a.Points not listed are not used in this application.
b.A single value in a column means that the value is the same in English units and in SI units.
c.Point numbers that appear in brackets { } may be unbundled at the field panel.
Detailed point descriptions
{94} LDO RESET FAULT NO - 1 0 RESET NO
{95} LAO MBOX PARAM - - 1 0 - -
{96} LAO MBOX DATA - - 1 0 - -
{97} LDO MBOX READ DONE - 1 0 READ DONE
{98} LDO MBOX WRITE DONE - 1 0 WRITE DONE
{99} LAO ERROR
STATUS
--10--
FLN Detailed Point Descriptions
Point Description
Drive
Parameter
1CTRL
ADDRESS
The FLN address of the drive. It can be set by FLN and
by the panel.
5302
2 APPLICATION The Application ID for FLN on the ACS320. This ID is
assigned by Siemens for each unique application. It
correlates directly to a particular point list approved at
the time of release. Therefore, this point list shall remain
fixed once approval is granted. Any changes to the point
list shall require a new Application ID and re-approval by
Siemens. The Application ID assigned to ACS320 is
2934.
3 FREQ OUTPUT The output frequency applied to the motor, in Hertz. 0103
4 PCT OUTPUT The ratio of output frequency or speed to the
corresponding maximum rating, depending on control
mode.
For scalar mode, it is the ratio of Output Frequency
(parameter 0103) to Maximum Frequency (parameter
2008).
None. This
ratio is
calculated
by the FLN
application.
5 SPEED The calculated speed of the motor, in RPM. 0102
6 CURRENT The measured output current. 0104
7 TORQUE The calculated output torque of the motor as a
percentage of nominal torque.
0105
8 POWER The measured output power in KW. The FLN point
definition also supports horsepower by selecting English
units.
0106
9 DRIVE TEMP The measured heatsink temperature, in
° C. The FLN
point definition also supports ° F by selecting English
units.
0110
10 DRIVE KWH The drive's cumulative power consumption in kilowatt-
hours. This value may be reset by commanding FLN
point 49, RESET KWH.
0115
FLN Point Database
Point
Subpoint Name
Factory
Default
Engr.
Units
Slope Intercept
On Text Off Text
# Type (SI Units)
To Next Page
