Program features 109
Programmable digital inputs
The drive has five programmable digital inputs. The update time for the digital inputs
is 2 ms.
It is possible to delay the state change of digital inputs with delays defined in group
Group 18: Freq in & tran out. This enables very simple program sequences by
connecting several functions with the same physical wire, eg, to remove branches
and leaves from a pipe by running the fan in reverse before normal operation.
One digital input (DI5) can be programmed as a frequency input. See section
Frequency input on page 111.
Settings
Parameter Additional information
Group 10: Start/Stop/Dir DI as start, stop, direction
Group 11: Reference select DI in reference selection, or reference source
Group 12: Constant speeds DI in constant speed selection
Group 16: System controls DI as external Run Enable, fault reset or user macro
change signal
Group 18: Freq in & tran out Delays in DI state changes
2115 Selects the source for controlling motor heating.
2109 DI as external emergency stop command source
2201 DI as acceleration and deceleration ramp selection
signal
2209 DI as zero ramp force signal
3003 DI as external fault source
Group 35: Motor temp meas DI in motor temperature measurement
3601 DI as timed function enable signal source
3622 DI as booster activation signal source
4010/4110/4210 DI as PID controller reference signal source
4022/4122 DI as sleep function activation signal in PID1
4027 DI as PID1 parameter set 1/2 selection signal source
4034/4035 DI as PID reference/output freezing source
4039/4139 DI as PID internal setpoint selection source
4228 DI as external PID2 function activation signal source
4406/4414 DI as connection signal source for pump inlet/outlet
pressure switch
4421 DI as pipe fill enable source
4601 DI as pump clean trigger source
6403 DI as load analyzer logger reset source
8120 DI as PFA interlock source
