242 Actual signals and parameters
4039
INT SETPNT SEL
NOT SEL
Selects the source for the selection of the internal setpoint used as the process PID
controller reference when parameter 4010 SET POINT SEL value is set to INTERNAL.
Example:
4010 SET POINT SEL = INTERNAL
4039 INT SETPNT SEL = DI2
Digital input DI2 = 1
-
> 4012 SETPOINT MIN is used as the reference.
0 = NOT SEL – 4011 INTERNAL SETPNT is used as the reference.
1 = DI1
0 = 4011 INTERNAL SETPNT is used.
1 = 4036 INTERNAL SETPNT2 is used.
2 = DI2 – See selection DI1.
3 = DI3 – See selection DI1.
4 = DI4 – See selection DI1.
5 = DI5 – See selection DI1.
7 = DI1,2 – Selects with digital inputs DI1 and DI2 which internal setpoint is used as
the reference. 1 = DI active, 0 = DI inactive.
8 = DI2,3 – See selection DI1,2.
9 = DI3,4 – See selection DI1,2.
10 = DI4,5 – See selection DI1,2.
15 = TIMED FUNC 1
0 = 4011 INTERNAL SETPNT is used.
1 = 4036 INTERNAL SETPNT2 is used.
16 = TIMED FUNC 2 – See selection TIMED FUNC 1.
17= TIMED FUNC 3 – See selection TIMED FUNC 1.
18= TIMED FUNC 4 – See selection TIMED FUNC 1.
19 = TIMED FUN1&2 – Selects with TIMED FUNC 1 and TIMED FUNC 2 which
internal setpoint is used as the reference. 1 = timed function active, 0 = timed
function inactive.
Group 40: Process PID set 1
Code Description Range Resolution Default S
DI1 DI2 Internal setpoint selected
004011 INTERNAL SETPNT
104036 INTERNAL SETPNT2
014037 INTERNAL SETPNT3
114038 INTERNAL SETPNT4
TIMED FUNC 1 TIMED FUNC 2 Internal setpoint selected
004011 INTERNAL SETPNT
104036 INTERNAL SETPNT2
014037 INTERNAL SETPNT3
114038 INTERNAL SETPNT4
