318 Fieldbus control
52 LAO PRC PID DTIM 0 SEC 0.1 0 - -
53 LAO PRC PID DFIL 10 SEC 0.1 0 - -
54 LDO PRC PID SEL SET1 - 1 0 SET2 SET1
55 LAO EXT PID GAIN 10 PCT 0.1 0 - -
56 LAO EXT PID ITIM 600 SEC 0.1 0 - -
57 LAO EXT PID DTIM 0 SEC 0.1 0 - -
58 LAO EXT PID DFIL 10 SEC 0.1 0 - -
59 LDO LOCK PANEL UNLOCK - 1 0 LOCK UNLOCK
{60} LAO INPUT REF1 0 PCT 0.1 0 - -
{61} LAO INPUT REF2 0 PCT 0.1 0 - -
{62} LAO EXT PID STPT 0 PCT 0.1 0 - -
{63} LAI EXT PID FBCK 0 PCT 0.1 0 - -
{64} LAI EXT PID DEV 0 PCT 0.1 0 - -
66 LDO SPD OUT MIN 0 PCT 0.1 0 - -
67 LDO SPD OUT MAX 1000 PCT 0.1 0 - -
{68} LDO FLN LOC CTL AUTO - 1 0 FLN AUTO
{69} LDO FLN LOC REF AUTO - 1 0 FLN AUTO
{70} LDI DI 1 ACTUAL OFF - 1 0 ON OFF
{71} LDI DI 2 ACTUAL OFF - 1 0 ON OFF
{72} LDI DI 3 ACTUAL OFF - 1 0 ON OFF
{73} LDI DI 4 ACTUAL OFF - 1 0 ON OFF
{74} LDI DI 5 ACTUAL OFF - 1 0 ON OFF
{76} LDI RO 1 ACTUAL OFF - 1 0 ON OFF
{77} LDI RO 2 ACTUAL OFF - 1 0 ON OFF
{78} LDI RO 3 ACTUAL OFF - 1 0 ON OFF
{79} LDI RO 4 ACTUAL OFF - 1 0 ON OFF
{82} LAI AI 1 ACTUAL 0 PCT 0.1 0 - -
{83} LAI AI 2 ACTUAL 0 PCT 0.1 0 - -
{84} LAI AO 1 ACTUAL 0 MA 0.1 0 - -
{86} LDI OK.ALARM OK - 1 0 ALARM OK
{87} LDI OK.MAINT OK - 1 0 MAINT OK
{88} LAI ALARM WORD
1
--10--
{89} LAI ALARM WORD
2
--10--
{90} LAI LAST FAULT - - 1 0 - -
{91} LAI PREV FAULT 1 - - 1 0 - -
{92} LAI PREV FAULT 2 - - 1 0 - -
{93} LDI OK.FAULT OK - 1 0 FAULT OK
FLN Point Database
Point
Subpoint Name
Factory
Default
Engr.
Units
Slope Intercept
On Text Off Text
# Ty pe (SI Units)
