Actual signals and parameters 151
0115
KWH COUNTER (R)
0 … 10000 h 1 h -
The drive’s accumulated power consumption in kilowatt hours.
Can be reset by pressing UP and DOWN buttons simultaneously when in
parameter set mode.
0116
APPL BLK OUTPUT
0 … 100%
(torque: 0 … 600%)
0.1% -
Application block output signal. Value is from either:
PFA control, if PFA Control is active, or
Parameter 0112 EXTERNAL REF 2.
0120
AI1
-100 … 100% 0.1% -
Relative value of analog input 1 in %.
0121
AI2
-100 … 100% 0.1% -
Relative value of analog input 2 in %.
0124
AO1
0 … 20 mA 0.1 mA -
The analog output 1 value in milliamperes.
0126
PID 1 OUTPUT
0 … 100% 0.1% -
The PID Controller 1 output value in %.
0127
PID 2 OUTPUT
0 … 100% 0.1% -
The PID Controller 2 output value in %.
0128
PID 1 SETPNT
---
The PID 1 controller setpoint signal.
Units and scale defined by PID parameters 4006/4106 & 4007/4107.
0129
PID 2 SETPNT
---
The PID 2 controller setpoint signal.
Units and scale defined by PID parameters 4206 & 4207.
0130
PID 1 FBK
---
The PID 1 controller feedback signal.
Units and scale defined by PID parameters 4006/4106 & 4007/4107.
0131
PID 2 FBK
---
The PID 2 controller feedback signal.
Units and scale defined by PID parameters 4206 & 4207.
0132
PID 1 DEVIATION
---
The difference between the PID 1 controller reference value and actual value.
Units and scale defined by PID parameters 4006/4106 & 4007/4107.
0133
PID 2 DEVIATION
---
The difference between the PID 2 controller reference value and actual value.
Units and scale defined by PID parameters 4206 & 4207.
Group 01: Operating data
Code Description Range Resolution Default S
