362 Fault tracing
2009 DEVICE
OVERTEMP
0308 bit 8
Drive IGBT
temperature is
excessive. Alarm limit
is 120 °C.
Check ambient conditions. See also
section Derating on page 386.
Check air flow and fan operation.
Check motor power against unit
power.
2010 MOTOR TEMP
0305 bit 9
(programmable fault
function
3005…3009 / 3503)
Motor temperature is
too high (or appears to
be too high) due to
excessive load,
insufficient motor
power, inadequate
cooling or incorrect
start-up data.
Check motor ratings, load and
cooling.
Check start-up data.
Check fault function parameters.
Measured motor
temperature has
exceeded alarm limit
set by parameter 3503
ALARM LIMIT.
Check value of alarm limit.
Check that actual number of sensors
corresponds to value set by
parameter (2501 SENSOR TYPE).
Let motor cool down. Ensure proper
motor cooling: Check cooling fan,
clean cooling surfaces, etc.
2012 MOTOR STALL
0308 bit 11
(programmable fault
function
3010…3012)
Motor is operating in
stall region due to, eg,
excessive load or
insufficient motor
power.
Check motor load and drive ratings.
Check fault function parameters.
2013
1)
AUTORESET
0308 bit 12
Automatic reset alarm Check parameter Group 31:
Automatic reset settings.
2014
1)
AUTOCHANGE
0308 bit 13
PFA autochange
function is active.
See parameter Group 81: PFA
control. See also section SPFC
control on page 138.
2015 PFC I LOCK
0308 bit 14
PFA interlocks are
active.
Drive cannot start
• any motor (when Autochange is
used)
• the speed regulated motor (when
Autochange is not used).
See parameter group Group 81: PFA
control.
2018
1)
PID SLEEP
3009 bit 1
Sleep function has
entered sleeping
mode.
See parameter Group 40: Process
PID set 1…Group 41: Process PID
set 2.
2020 OVERRIDE Override mode is
activated. See Group
17: Override.
See sections Commissioning the
override mode and Changing the
override parameters.
2021 START ENABLE 1
MISSING
3009 bit 4
No Start Enable 1
signal received
Check parameter 1608 START
ENABLE 1settings.
Check digital input connections.
Check fieldbus communication
settings.
CODE ALARM CAUSE WHAT TO DO
