Actual signals and parameters 171
-12 = DI1,2,3(INV) – Selects one of seven constant speeds (1...7) using DI1, DI2 and
DI3.
• Inverse operation uses three digital inputs, as defined below (0 = DI de-activated,
1 = DI activated):
-13 = DI3,4,5(INV) – Selects one of seven constant speeds (1…3) using DI3, DI4 and
DI5.
• See above (DI1,2,3(INV)) for code.
1202
CONST SPEED 1
0.0 … 500.0 Hz 0.1 Hz 6.0 (US)
Defines constant speed 1 (drive output frequency).
1203
CONST SPEED 2
0.0 … 500.0 Hz 0.1 Hz 12.0
Defines constant speed 2 (drive output frequency).
1204
CONST SPEED 3
0.0 … 500.0 Hz 0.1 Hz 18.0
Defines constant speed 3 (drive output frequency).
1205
CONST SPEED 4
0.0 … 500.0 Hz 0.1 Hz 24.0
Defines constant speed 4 (drive output frequency).
1206
CONST SPEED 5
0.0 … 500.0 Hz 0.1 Hz 30.0
Defines constant speed 5 (drive output frequency).
1207
CONST SPEED 6
0.0 … 500.0 Hz 0.1 Hz 48.0
Defines constant speed 6 (drive output frequency).
1208
CONST SPEED 7
0.0 … 500.0 Hz 0.1 Hz 60.0
Defines constant speed 7 (drive output frequency).
Group 12: Constant speeds
Code Description Range Resolution Default S
DI1 DI2 DI3 Function
1 1 1 No constant speed
0 1 1 Constant speed 1 (1202)
1 0 1 Constant speed 2 (1203)
0 0 1 Constant speed 3 (1204)
1 1 0 Constant speed 4 (1205)
0 1 0 Constant speed 5 (1206)
1 0 0 Constant speed 6 (1207)
0 0 0 Constant speed 7 (1208)
