Actual signals and parameters 193
2103
DC MAGN TIME
0.00 … 10.00 s 0.01 s 0.30 s
Defines the pre-magnetizing time for the DC Magnetizing start mode.
• Use parameter 2101 START FUNCTION to select the start mode.
• After the start command, the drive pre-magnetizes the motor for the time defined
here, and then starts the motor.
• Set the pre-magnetizing time just long enough to allow full motor magnetization. Too
long a time heats the motor excessively.
2104
DC HOLD CTL
0...3 1 0
Enables or disables the Motor heating function. The function keeps the motor warm at
low temperatures.
0 = NOT SEL – Disables the Motor heating function.
1 = MOT. HEATING – Enables the Motor heating function. The function is activated by
parameter 2115 MOT. HEATING SEL.
2106
DC CURR REF
0 … 100% 1% 30%
Defines the DC current control reference as a percentage of parameter 9906 MOTOR
NOM CURR.
2107
DC BRAKE TIME
0 … 250 s 0.1 s 0 s
Defines the DC brake time.
Note: DC brake is activated when value is greater than 0.
2108
START INHIBIT
0, 1 1 0
Sets the Start inhibit function on or off. If the drive is not actively started and running,
the Start inhibit function ignores a pending start command in any of the following
situations and a new start command is required:
• Fault is reset.
• Run enable (parameter 1601 RUN ENABLE) activates while start command is
active.
• Mode changes from local to remote.
• Control switches from EXT1 to EXT2Control switches from EXT2 toEXT1.
0 = OFF – Disables the Start inhibit function.
1 = ON – Enables the Start inhibit function.
Group 21: Start/Stop
Code Description Range Resolution Default S
