Actual signals and parameters 175
Actual signals and parameters
What this chapter contains
The chapter describes the actual signals and parameters and gives the fieldbus
equivalent values for each signal/parameter. It also contains a table of the default
values for the different macros.
Terms and abbreviations
Fieldbus addresses
For FCAN-01 CANopen adapter, FDNA-01 DeviceNet adapter, FECA-01 EtherCAT
adapter, FENA-01 Ethernet adapter, FMBA-01 Modbus adapter, FLON-01
LonWorks® adapter, and FPBA-01 PROFIBUS DP adapter, see the user’s manual of
the adapter.
Term Definition
Actual signal Signal measured or calculated by the drive. Can be monitored by the user.
No user setting possible. Groups 01…04 contain actual signals.
Def Parameter default value
Parameter A user-adjustable operation instruction of the drive. Groups 10…99 contain
parameters.
Note: Parameter selections are shown on the basic control panel as integer
values. Eg parameter 1001 EXT1 COMMANDS selection COMM is shown as
value 10 (which is equal to the fieldbus equivalent FbEq).
FbEq Fieldbus equivalent: The scaling between the value and the integer used in
serial communication.
E Refers to types 01E- and 03E- with European parametrization
U Refers to types 01U- and 03U- with US parametrization
