256 Actual signals and parameters
3420 OUTPUT3 MIN Sets the minimum display value for the signal selected by
parameter 3415 SIGNAL3 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3415 SIGNAL3
PARAM setting.
-
3421 OUTPUT3
MAX
Sets the maximum display value for the signal selected by
parameter 3415 SIGNAL3 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3415 setting. -
35 MOTOR TEMP
MEAS
Motor temperature measurement. See section Motor
temperature measurement through the standard I/O on
page 155.
3501 SENSOR
TYPE
Activates the motor temperature measurement function and
selects the sensor type. See also parameter group 15
ANALOG OUTPUTS.
NONE
NONE The function is inactive. 0
1 x PT100 The function is active. The temperature is measured with
one Pt 100 sensor. Analog output AO feeds constant current
through the sensor. The sensor resistance increases as the
motor temperature rises, as does the voltage over the
sensor. The temperature measurement function reads the
voltage through analog input AI1/2 and converts it to
degrees centigrade.
1
2 x PT100 The function is active. Temperature is measured using two
Pt 100 sensors. See selection 1 x PT100.
2
3 x PT100 The function is active. Temperature is measured using three
Pt 100 sensors. See selection 1 x PT100.
3
All parameters
No. Name/Value Description Def/FbEq
