 List of the tasks and the relevant drive parameters
Depending on the selection made in the Application task (parameter 9902 APPLIC
MACRO), the Start-up assistant decides which consequent tasks it suggests.
Name Description Set parameters
Language select Selecting the language 9901
Motor set-up Setting the motor data
Performing the motor identification. (If the
speed limits are not in the allowed range:
Setting the limits.)
9904…9909
9910
Application Selecting the application macro 9902, parameters
associated to the macro
Option modules Activating the option modules Group 35 MOTOR TEMP
MEAS, group 52 PANEL
COMM
9802
Speed control EXT1 Selecting the source for the speed
reference
1103
(If AI1 is used: Setting analog input AI1
limits, scale, inversion)
(1301…1303, 3001)
Setting the reference limits 1104, 1105
Setting the speed (frequency) limits 2001, 2002 (2007, 2008)
Setting the acceleration and deceleration
times
2202, 2203
Speed control EXT2 Selecting the source for the speed
reference
1106
(If AI1 is used: Setting analog input AI1
limits, scale, inversion)
(1301…1303, 3001)
Setting the reference limits 1107, 1108
Torque control Selecting the source for the torque
reference
1106
(If AI1 is used: Setting analog input AI1
limits, scale, inversion)
(1301…1303, 3001)
Setting the reference limits 1107, 1108
Setting the torque ramp up and ramp down
times
2401, 2402
PID control Selecting the source for the process
reference
1106
(If AI1 is used: Setting analog input AI1
limits, scale, inversion)
(1301…1303, 3001)
Setting the reference limits 1107, 1108
Setting the speed (frequency) limits 2001, 2002 (2007, 2008)
Setting the source and limits for the
process actual value
4016, 4018, 4019
