Transistor output
The drive has one programmable transistor output. The output can be used either as
a digital output or frequency output (0…16000 Hz). The update time for the
transistor/frequency output is 2 ms.
 Settings
 Diagnostics
Actual signals
Several actual signals are available:
• Drive output frequency, current, voltage and power
• Motor speed and torque
• Intermediate circuit DC voltage
• Active control location (LOCAL, EXT1 or EXT2)
• Reference values
• Drive temperature
• Operating time counter (h), kWh counter
• Digital I/O and analog I/O status
• PID controller actual values.
Three signals can be shown simultaneously on the assistant control panel display
(one signal on the basic control panel display). It is also possible to read the values
through the serial communication link or through the analog outputs.
 Settings
Parameter Additional information
Group 18 FREQ IN & TRAN OUT Transistor output settings
8423 Transistor output control with Sequence programming
Actual signal Additional information
0163 Transistor output status
0164 Transistor output frequency
Parameter Additional information
1501 Selection of an actual signal to AO
1808 Selection of an actual signal to frequency output
Group 32 SUPERVISION Actual signal supervision
Group 34 PANEL DISPLAY Selection of an actual signals to be displayed on the
control panel
