168 Program features
 State shifts
Sequence programming
ENABLE
Go to state N (par 8426, 8427)*
STATE 1
(par. 8420…8424)
STATE 2
(par. 8430…8434)
STATE 3
(par. 8440…8444)
STATE 4
(par. 8450…8454)
STATE 5
(par. 8460…8464)
STATE 6
(par. 8470…8474)
STATE 7
(par. 8480…8484)
STATE 8
(par. 8490…8494)
Go to state N (par 8436 , 8437 )*
Go to state N (par
8446 , 8447 )*
Go to state N (par
8456 , 8457 )*
Go to state N (par
8466 , 8467 )*
Go to state N (par
8476 , 8477 )*
Go to state N (par
8486 , 8487 )*
Go to state N (par
8496 , 8497 )*
Go to state 3 (par
8435 )*
Go to state 2 (par 8425)*
Go to state 4 (par
8445 )*
Go to state 5 (par
8455 )*
Go to state 6 (par
8465 )*
Go to state 7 (par
8475 )*
Go to state 8 (par
8485 )*
Go to state 1 (par
8495 )*
State N
State N
State N
State N
State N
State N
State N
State N
0167 bit 0 = 1
0168 = 1 (State 1)
0168 = 2 (State 2)
0168 = 3 (State 3)
0168 = 4 (State 4)
0168 = 5 (State 5)
0168 = 6 (State 6)
0168 = 7 (State 7)
0168 = 8 (State 8)
NN
X
State change
NN = State
X = Actual signal
*State change to state N has a
higher priority than state change to
the next state.
