Control panels
What this chapter contains
The chapter describes the control panel keys, LED indicators and display fields. It
also instructs in using the panel in control, monitoring and changing the settings.
About control panels
Use a control panel to control the ACS355, read status data, and adjust parameters.
The drive works with either of two different control panel types:
• Basic control panel – This panel (described in section Basic control panel on page
75) provides basic tools for manual entry of parameter values.
• Assistant control panel – This panel (described in section Assistant control panel
on page 87) includes pre-programmed assistants to automate the most common
parameter setups. The panel provides language support. It is available with
different language sets.
Applicability
The manual is applicable to panels with the panel revisions and the panel firmware
versions given in the table below.
Panel type Type code Panel revision Panel firmware
version
Basic control panel ACS-CP-C M or later 1.13 or later
Assistant control panel ACS-CP-A F or later 2.04 or later
Assistant control panel (Asia) ACS-CP-D Q or later 2.04 or later
