ABB ACS355 User Manual

Operation principle and hardware description 29
Type designation key
The type designation contains information on the specifications and configuration of
the drive. You find the type designation on the type designation label attached to the
drive. The first digits from the left express the basic configuration, for example
ACS355-03E-09A7-4. The optional selections are given after that, separated by +
signs, for example +J404. The explanations of the type designation selections are
described below.
ACS355 product series
01 = 1-phase input
03 = 3-phase input
1-phase/3-phase
In format xxAy, where xx indicates the integer part and y the fractional part,
eg 09A7 means 9.7 A.
For more information, see section Ratings on page 358.
2 = 200…240 V AC
4 = 380…480 V AC
Input voltage range
E = EMC filter connected, 50 Hz frequency
U = EMC filter disconnected, 60 Hz frequency
Configuration
1) The ACS355 is compatible with panels that have the following panel revisions and panel
firmware versions. To find out the revision and firmware version of your panel, see page 74.
Note that unlike the other panels, the ACS-CP-D is ordered with a separate material code.
Panel type Type code Panel revision Panel firmware
version
Basic control panel ACS-CP-C M or later 1.13 or later
Assistant control panel ACS-CP-A F or later 2.04 or later
Assistant control panel (Asia) ACS-CP-D Q or later 2.04 or later
Options
ACS355-03E-09A7-4+J404+...
Output current rating
B063 = IP66/IP67/UL Type 4x enclosure
(product variant)
J400 = ACS-CP-A assistant control panel
1)
J404 = ACS-CP-C basic control panel
1)
J402 = MPOT-01 potentiometer
K451 = FDNA-01 DeviceNet
K454 = FPBA-01 PROFIBUS DP
K457 = FCAN-01 CANopen
K458 = FMBA-01 Modbus RTU
K466 = FENA-01 EtherNet/IP / Modbus TCP/IP
K452 = FLON-01 LonWorks
K469 = FECA-01 EtherCAT
H376 = Cable gland kit (IP66/IP67/UL Type 4x)
F278 = Input switch kit
C169 = Pressure compensation valve
Extension modules
G406 = MPOW-01auxiliary power module
L502 = MTAC-01 pulse encoder module
L511 = MREL-01 relay output module

ABB ACS355 Specifications

General

Input Voltage	200 V to 240 V AC, 380 V to 480 V AC
Frequency	47 Hz to 63 Hz
Control Method	Scalar control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Modbus RTU, CANopen
Enclosure Rating	IP20
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Storage Temperature	-40°C to +70°C (-40 to +158 °F)
Humidity	95% RH (non-condensing)
Altitude	Up to 1000 m (3280 ft) without derating
