Installation checklist 57
Installation checklist
Checking the installation
Check the mechanical and electrical installation of the drive before start-up. Go
through the checklist below together with another person. Read chapter Safety on
page 17 of this manual before you work on the drive.
Check
MECHANICAL INSTALLATION
The ambient operating conditions are allowed. (See Mechanical installation: Checking the
installation site on page 31 as well as Technical data: Losses, cooling data and noise on
page 364 and Ambient conditions on page 371.)
The drive is fixed properly on an even vertical non-flammable wall. (See Mechanical
installation on page 31.)
The cooling air will flow freely. (See Mechanical installation: Free space around the drive
on page 32.)
The motor and the driven equipment are ready for start. (See Planning the electrical
installation: Checking the compatibility of the motor and drive on page 38 as well as
Technical data: Motor connection data on page 367.)
ELECTRICAL INSTALLATION (See Planning the electrical installation on page 37 and
Electrical installation on page 47.)
For ungrounded and corner-grounded systems: The internal EMC filter is disconnected
(EMC screw removed).
The capacitors are reformed if the drive has been stored over a year.
The drive is grounded properly.
The input power voltage matches the drive nominal input voltage.
The input power connections at U1, V1 and W1 are OK and tightened with the correct
torque.
