Actual signals and parameters 293
COMM VAL1
#2
0135 COMM VALUE 1 bit 2. 1 = state change. 72
COMM VAL1
#3
0135 COMM VALUE 1 bit 3. 1 = state change. 73
COMM VAL1
#4
0135 COMM VALUE 1 bit 4. 1 = state change. 74
COMM VAL1
#5
0135 COMM VALUE 1 bit 5. 1 = state change. 75
COMM VAL1
#6
0135 COMM VALUE 1 bit 6. 1 = state change. 76
COMM VAL1
#7
0135 COMM VALUE 1 bit 7. 1 = state change. 77
AI2H2DI4SV1O State change according to supervision parameters
3201…3203 when AI2 value > par. 8413 SEQ VAL 2 HIGH
value and DI4 is active.
78
AI2H2DI5SV1O State change according to supervision parameters
3201…3203 when AI2 value > par. 8413 SEQ VAL 2 HIGH
value and DI5 is active.
79
STO State change when STO (Safe torque off) has been
triggered.
80
STO(-1) State change when STO (Safe torque off) becomes inactive
and the drive operates normally.
81
8426 ST1 TRIG TO
ST N
Selects the source for the trigger signal which changes the
state from state 1 to state N. State N is defined with
parameter 8427 ST1 STATE N.
Note: State change to state N (8426 ST1 TRIG TO ST N)
has a higher priority than state change to the next state
(8425 ST1 TRIG TO ST 2).
NOT SEL
See parameter 8425 ST1 TRIG TO ST 2.
8427 ST1 STATE N Defines the state N. See parameter 8426 ST1 TRIG TO ST
N.
STATE 1
STATE 1 State 1 1
STATE 2 State 2 2
STATE 3 State 3 3
STATE 4 State 4 4
STATE 5 State 5 5
STATE 6 State 6 6
STATE 7 State 7 7
STATE 8 State 8 8
8430 ST2 REF SEL
See parameters 8420…8427.
…
8497 ST8 STATE N
All parameters
No. Name/Value Description Def/FbEq
