Actual signals and parameters 285
NOT SEL Logic value 1 (no logic comparison) 0
AND Logic function: AND 1
OR Logic function: OR 2
XOR Logic function: XOR 3
8408 SEQ LOGIC
VAL 2
See parameter 8406 SEQ LOGIC VAL 1. NOT SEL
See parameter 8406.
8409 SEQ LOGIC
OPER 2
Selects the operation between logic value 3 and the result
of the first logic operation defined by parameter 8407 SEQ
LOGIC OPER 1.
NOT SEL
NOT SEL Logic value 2 (no logic comparison) 0
AND Logic function: AND 1
OR Logic function: OR 2
XOR Logic function: XOR 3
8410 SEQ LOGIC
VAL 3
See parameter 8406 SEQ LOGIC VAL 1. NOT SEL
See parameter 8406.
8411 SEQ VAL 1
HIGH
Defines the high limit for the state change when parameter
8425 ST1 TRIG TO ST 2 is set to eg AI 1 HIGH 1.
0.0%
0.0…100.0% Value in percent 1 = 0.1%
8412 SEQ VAL 1
LOW
Defines the low limit for the state change when parameter
8425 ST1 TRIG TO ST 2 is set to eg AI 1 LOW 1.
0.0%
0.0…100.0% Value in percent 1 = 0.1%
8413 SEQ VAL 2
HIGH
Defines the high limit for the state change when parameter
8425 ST1 TRIG TO ST 2 is set to eg AI 2 HIGH 1.
0.0%
0.0…100.0% Value in percent 1 = 0.1%
8414 SEQ VAL 2
LOW
Defines the low limit for the state change when parameter
8425 ST1 TRIG TO ST 2 is set to eg AI 2 LOW 1.
0.0%
0.0…100.0% Value in percent 1 = 0.1%
8415 CYCLE CNT
LOC
Activates the cycle counter for Sequence programming.
Example: When parameter is set to ST6 TO NEXT, the
cycle count (0171 SEQ CYCLE CNTR) increases every
time the state changes from state 6 to state 7.
NOT SEL
NOT SEL Disabled 0
ST1 TO NEXT From state 1 to state 2 1
ST2 TO NEXT From state 2 to state 3 2
ST3 TO NEXT From state 3 to state 4 3
ST4 TO NEXT From state 4 to state 5 4
ST5 TO NEXT From state 5 to state 6 5
ST6 TO NEXT From state 6 to state 7 6
ST7 TO NEXT From state 7 to state 8 7
ST8 TO NEXT From state 8 to state 1 8
All parameters
