286 Actual signals and parameters
ST1 TO N From state 1 to state n. State n is defined by parameter
8427 ST1 STATE N.
9
ST2 TO N From state 2 to state n. State n is defined by parameter
8427 ST1 STATE N.
10
ST3 TO N From state 3 to state n. State n is defined by parameter
8427 ST1 STATE N.
11
ST4 TO N From state 4 to state n. State n is defined by parameter
8427 ST1 STATE N.
12
ST5 TO N From state 5 to state n. State n is defined by parameter
8427 ST1 STATE N.
13
ST6 TO N From state 6 to state n. State n is defined by parameter
8427 ST1 STATE N.
14
ST7 TO N From state 7 to state n. State n is defined by parameter
8427 ST1 STATE N.
15
ST8 TO N From state 8 to state n. State n is defined by parameter
8427 ST1 STATE N.
16
8416 CYCLE CNT
RST
Selects the source for the cycle counter reset signal (0171
SEQ CYCLE CNTR).
NOT SEL
DI1(INV) Reset through inverted digital input DI1. 0 = active, 1 =
inactive.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
NOT SEL No reset signal 0
DI1 Reset through digital input DI1. 1 = active, 0 = inactive. 1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
STATE 1 Reset during state transition to state 1. Counter is reset,
when the state has been reached.
6
STATE 2 Reset during state transition to state 2. Counter is reset,
when the state has been reached.
7
STATE 3 Reset during state transition to state 3. Counter is reset,
when the state has been reached.
8
STATE 4 Reset during state transition to state 4. Counter is reset,
when the state has been reached.
9
STATE 5 Reset during state transition to state 5. Counter is reset,
when the state has been reached.
10
STATE 6 Reset during state transition to state 6. Counter is reset,
when the state has been reached.
11
All parameters
No. Name/Value Description Def/FbEq
