Actual signals and parameters 255
3409 SIGNAL2 MIN Defines the minimum value for the signal selected by
parameter 3408 SIGNAL2 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3408 setting. -
3410 SIGNAL2 MAX Defines the maximum value for the signal selected by
parameter 3408 SIGNAL2 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3408 setting. -
3411 OUTPUT2 DSP
FORM
Defines the format for the displayed signal selected by
parameter 3408 SIGNAL2 PARAM.
DIRECT
See parameter 3404 OUTPUT1 DSP FORM.-
3412 OUTPUT2
UNIT
Selects the unit for the displayed signal selected by
parameter 3408 SIGNAL2 PARAM.
-
See parameter 3405 OUTPUT1 UNIT.-
3413 OUTPUT2 MIN Sets the minimum display value for the signal selected by
parameter 3408 SIGNAL2 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3408 setting. -
3414 OUTPUT2
MAX
Sets the maximum display value for the signal selected by
parameter 3408 SIGNAL2 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3408 setting. -
3415 SIGNAL3
PARAM
Selects the third signal to be displayed on the control panel
in the Output mode. See parameter 3401 SIGNAL1
PARAM.
105
0= NOT
SELECTED
101…180
Parameter index in group 01 OPERATING DATA. Eg 102 =
0102 SPEED. If value is set to 0, no signal is selected.
1 = 1
3416 SIGNAL3 MIN Defines the minimum value for the signal selected by
parameter 3415. See parameter 3402 SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3415 SIGNAL3
PARAM setting.
-
3417 SIGNAL3 MAX Defines the maximum value for the signal selected by
parameter 3415 SIGNAL3 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3415 SIGNAL3
PARAM setting.
-
3418 OUTPUT3 DSP
FORM
Defines the format for the displayed signal selected by
parameter 3415 SIGNAL3 PARAM.
DIRECT
See parameter 3404 OUTPUT1 DSP FORM.-
3419 OUTPUT3
UNIT
Selects the unit for the displayed signal selected by
parameter 3415 SIGNAL3 PARAM.
-
See parameter 3405 OUTPUT1 UNIT.-
All parameters
No. Name/Value Description Def/FbEq
