184 Actual signals and parameters
0403 FAULT TIME 2 Time at which the latest fault occurred.
Format on the assistant control panel: Real time (hh:mm:ss)
if the real time clock is operating. / Time elapsed after the
power-on (hh:mm:ss minus the whole days stated by signal
0402 FAULT TIME 1) if real time clock is not used, or was
not set.
Format on the basic control panel: Time elapsed after
power-on in 2 second ticks (minus the whole days stated by
signal 0402 FAULT TIME 1). 30 ticks = 60 seconds. Eg
value 514 equals 17 minutes and 8 seconds (= 514/30).
1 = 2 s
0404 SPEED AT FLT Motor speed in rpm at the time the latest fault occurred 1 = 1 rpm
0405 FREQ AT FLT Frequency in Hz at the time the latest fault occurred 1 = 0.1 Hz
0406 VOLTAGE AT
FLT
Intermediate circuit voltage in V DC at the time the latest
fault occurred
1 = 0.1 V
0407 CURRENT AT
FLT
Motor current in A at the time the latest fault occurred 1 = 0.1 A
0408 TORQUE AT
FLT
Motor torque in percent of the motor nominal torque at the
time the latest fault occurred
1 = 0.1%
0409 STATUS AT
FLT
Drive status in hexadecimal format at the time the latest
fault occurred
0412 PREVIOUS
FAULT 1
Fault code of the 2nd latest fault. See chapter Fault tracing
on page 335 for the codes.
1 = 1
0413 PREVIOUS
FAULT 2
Fault code of the 3rd latest fault. See chapter Fault tracing
on page 335 for the codes.
1 = 1
0414 DI 1-5 AT FLT Status of digital inputs DI1…5 at the time the latest fault
occurred (binary).
Example: 10000 = DI1 is on, DI2…DI5 are off.
Actual signals
No. Name/Value Description FbEq
