Fieldbus control with embedded fieldbus 323
12 PANEL_LOCAL 1 Control is in control panel (or PC tool) local mode.
0 Control is not in control panel local mode.
13 FIELDBUS_LOCAL 1 Control is in fieldbus local mode
0 Control is not in fieldbus local mode.
14 EXT2_ACT 1 Control is in EXT2 mode.
0 Control is in EXT1 mode.
15 FAULT 1 Drive is in a fault state.
0 Drive is not in a fault state.
DCU profile Status word, parameter 0304 FB STS WORD 2
Bit Name Value Status
16 ALARM 1 An alarm is on.
0 No alarms are on.
17 NOTICE 1 A maintenance request is pending.
0 No maintenance request
18 DIRLOCK 1 Direction lock is ON. (Direction change is locked.)
0 Direction lock is OFF.
19 LOCALLOCK 1 Local mode lock is ON. (Local mode is locked.)
0 Local mode lock is OFF.
20 CTL_MODE 1 Drive is in vector control mode.
0 Drive is in scalar control mode.
21 JOGGING ACTIVE 1 Jogging function is active.
0 Jogging function is not active.
22…
25
Reserved
26 REQ_CTL 1 Control word requested from fieldbus
0 No operation
27 REQ_REF1 1 Reference 1 requested from fieldbus
0 Reference 1 is not requested from fieldbus.
28 REQ_REF2 1 Reference 2 requested from fieldbus
0 Reference 2 is not requested from fieldbus.
29 REQ_REF2EXT 1 External PID reference 2 requested from fieldbus
0 External PID reference 2 is not requested from
fieldbus.
30 ACK_STARTINH 1 Start inhibit from fieldbus
0 No start inhibit from fieldbus
31 Reserved
DCU profile Status word, parameter 0303 FB STS WORD 1
Bit Name Value Status
