How to set the speed, frequency or torque reference
How to adjust the display contrast
Step Action Display
1. If you are not in the Output mode, press repeatedly
until you get there.
2. If the drive is in remote control (REM shown on the status
line), switch to local control by pressing . The display
briefly shows a message about changing the mode and
then returns to the Output mode.
Note: With group 11 REFERENCE SELECT, you can
allow the reference modification in remote control.
3. • To increase the highlighted reference value shown in
the top right corner of the display, press . The
value changes immediately. It is stored in the drive
permanent memory and restored automatically after
power switch-off.
• To decrease the value, press .
Step Action Display
1. If you are not in the Output mode, press repeatedly
until you get there.
2. • To increase the contrast, press keys and
simultaneously.
• To decrease the contrast, press keys and
simultaneously.
