ABB ACS55 - Dati dimensionali

IT 131
Dati dimensionali
f
e
Telaio
A
mm
(in.)
Telaio
B
mm
(in.)
Telaio
C
mm
(in.)
Telaio
D
mm
(in.)
a53
(2,09)
72
(2,83)
74
(2,91)
74
(2,91)
b45
(1,77)
67,5
(2,66)
70
(2,76)
70
(2,76)
c128
(5,04)
128
(5,04)
159
(6,26)
159
(6,26)
d67,5
(2,66)
67,5
(2,66)
--
e- - 77
(3,03)
77
(3,03)
f- - 40
(1,57)
40
(1,57)
g- - 40
(1,57)
40
(1,57)
h183
(7,20)
183
(7,20)
- 230
(9,06)
i156
(6,14)
156
(6,14)
182
(7,17)
214
(8,43)
j170
(6,69)
170
(6,69)
194
(7,64)
226
(8,90)
k146,5
(5,77)
146,5
(5,77)
171
(6,73)
203
(7,99)
b
a
d
c
g
h
i j
k
