II K 6-18
Operating Instructions
Set parameters
Arm Cur Nom (1.01): see motor name plate
Arm Volt Nom (1.02): see motor name plate
Field Cur Nom (1.03): see motor name plate
Field Volt Nom (1.04): see motor name plate
Base Speed (1.05): see motor name plate
Max Speed (1.06): same as Base Speed
with EMF feedback
Switch the drive ON and increase speed reference
slowly up to approx. 10% of Base Speed (1.05) by
using a reference potentiometer or by using the DCS
400 operating panel in LOCal mode.
To complete commissioning refer to appendix D -
Examples for basic parameter programming.
Set parameters
Eme Stop Mode (2.04): Coast
Speed Meas Mode (5.02): EMF
Contr Service (7.02): Fld Autotun
Contr Service (7.02): Arm Autotun
Check direction of rotation
on motor shaft
right direction
wrong direction
Switch the drive OFF, disconnect mains and elec-
tronics supply and change the connection of arma-
ture or field.
Switch the drive Off
