II K 4-45
Overview of Software
ParNo. Parameter name and significance Min Max Default Unit (1)
custom
setting
Grp 1 Motor Settings
1.01
Wizard
Arm Cur Nom
Nominal motor current in amperes
(indicated on the motor’s rating plate).
41000
(2)
4A x
1.02
Wizard
Arm Volt Nom
Nominal motor voltage in volts
(indicated on the motor’s rating plate).
50 700 50 V x
1.03
Wizard
Field Cur Nom
Nominal field current in amperes
(indicated on the motor’s rating plate).
0.10 20.00
(2)
0.40 A x
1.04
Wizard
Field Volt Nom
Nominal field voltage in volts
(indicated on the motor’s rating plate).
50 440 310 V x
1.05
Wizard
Base Speed
Nominal motor speed in revolutions/minute
(indicated on the motor’s rating plate).
Base Speed = Max Speed = no Fieldweakening
Base Speed < Max Speed = Fieldweakening
100 6500 100 rpm x
1.06
Wizard
Max Speed
Maximum motor speed in revolutions/minute
(indicated on the motor’s rating plate).
Base Speed = Max Speed = no Fieldweakening
Base Speed < Max Speed = Fieldweakening
100 6500 100 rpm x
1.07
Signal
Mains Volt Act
Measured mains voltage in volts.
---V
1.08
Signal
Mains Freq Act
Measured mains frequency in hertz.
---Hz
Long Parameter Menu
1.09 Arm Overv Trip
Motor overvoltage tripping limit in % related to the
nominal motor voltage (1.02)
20 150 130 %
1.10 Net Underv Trip
Trip level for mains undervoltage.
The power part of the DCS400 can operate on a
supply voltage of 230…500 V. A parameter setting
based on this is therefore not possible. The
minimum allowable mains voltage is calculated from
the parameter nominal motor voltage Arm Volt Nom
(1.02). If the mains voltage falls below the
calculated voltage the drive switches off and gives
an alarm F09.
The minimum voltage is calculated with
U
mains
≥
Ua / (1,35 x cos alpha)
cos alpha: 4Q = 30° = 0,866
2Q = 15° = 0,966
4Q: U
mains
≥
Ua / (1,35 x 0,866)
2Q: U
mains
≥
Ua / (1,35 x 0,966)
This parameter defines an additional safety margin
over the minimum allowable mains voltage.
-10 50 0 %
(1) no changes possible if the drive is in ON-status
(2) depends on converter's Typecode
