II K 4-62
Overview of Software
ParNo. Parameter name and significance Min Max Default Unit (1)
custom.
setting
Grp 6 Input / Output (continued)
6.12
Wizard
DO2 Assign
D
esired assignment of digital output 2:
Assignment identical with DO1 (6.11).
0 64 2 Text
6.13
Wizard
DO3 Assign
Desired assignment of digital output 3:
Assignment identical with DO1 (6.11).
0 64 2 Text
6.14
Wizard
DO4 Assign
Desired assignment of digital output 4:
Assignment identical with DO1 (6.11).
0 64 2 Text
6.15
Wizard
DO5 Assign
Desired assignment of digital output 5:
(relay X98:1-2):
Assignment identical with DO1 (6.11).
0 64 2 Text
6.16 Panel Act 1
Selection of the desired panel display of actual
value 1:
(top left corner of display)
0 = Speed Act / speed actual value (5.05)
1 = Speed Ref / speed reference value (5.04)
2 = Arm Volt Act / armature voltage act. value (3.03)
3 = Arm Cur Ref / armature current ref. (3.01)
4 = Arm Cur Act / armature current act. value (3.02)
5 = Power Act / actual power (3.21)
6 = Torque Act / torque actual value (3.23)
7 = Fld Cur Act / field current actual value (4.02)
8 = AI1 Act / Analogue Input 1 actual value (6.26)
9 = AI2 Act / Analogue Input 2 actual value (6.27)
10 = DI Act / Actual value DI1…8 (6.28)
11 = Ramp In Act / Speed ref. at ramp gen. input (5.23)
0 11 2 Text
6.17 Panel Act 2
Selection of the desired panel display of actual
value 2:
(top centre of display)
Assignment identical with Panel Act 1 (6.16)
0 11 4 Text
6.18 Panel Act 3
Selection of the desired panel display of actual
value 3:
(top right corner of display)
Assignment identical with Panel Act 1 (6.16)
0 11 1 Text
6.19 Panel Act 4
Selection of the desired panel display of actual
value 4:
(bottom of display)
Assignment identical with Panel Act 1 (6.16)
0 11 0 Text
(1) no chan
g
es possible if the drive is in ON-status
