II K 4-69
Overview of Software
ParNo. Parameter name and significance Min Max Default Unit
(1)
custom.
setting
Grp 7 Maintenance (continued)
7.12
Signal
Alarm Word 1
Alarm word 1. Significance of the individual bits:
All the pending alarms are displayed if the
corresponding bits are set to log. "1".
Bit hex Alarm definition
00 0001 01 Parameters Added
01 0002 02 Mains Voltage Low
02 0004 03 Arm Circuit Break
03 0008 04 Converter Temp High
04 0010 05 Motor Temp High
05 0020 06 Arm Current Reduced
06 0040 07 Field Volt Limited
07 0080 08 Mains Drop Out
08 0100 09 Eme Stop Pending
09 0200 10 Autotuning Failed
10 0400 11 Comm Interrupt
11 0800 12 External Alarm
12 1000 13 ill Fieldbus Setting
13 2000 14 Up/Download Failed
14 4000 15 PanTxt Not UpToDate
15 8000 16 Par Setting Conflict
- - - hex
7.13
Signal
Alarm Word 2
Alarm word 2. Significance of the individual bits:
All the pending alarms are displayed if the
corresponding bits are set to log. "1".
Bit hex Alarm definition
00 0001 17 Compatibility Alarm
01 0002 18 Parameter restored
02 0004 19 -
03 0008 20 -
04 0010 21 -
05 0020 22 -
06 0040 23 -
07 0080 24 -
08 0100 25 -
09 0200 26 -
10 0400 27 -
11 0800 28 -
12 1000 29 -
13 2000 30 -
14 4000 31 -
15 8000 32 -
- - - hex
7.14
Signal
Alarm Word 3
Alarm word 3. Significance of the individual bits:
All the pending alarms are displayed if the
corresponding bits are set to log. "1".
Bit hex Alarm definition
00 0001 33 -
01 0002 34 -
02 0004 35 -
03 0008 36 -
04 0010 37 -
05 0020 38 -
06 0040 39 -
07 0080 40 -
08 0100 41 -
09 0200 42 -
10 0400 43 -
11 0800 44 -
12 1000 45 -
13 2000 46 -
14 4000 47 -
15 8000 48 -
- - - hex
(1) no changes possible if the drive is in ON-status
