Description of the charging station
Operating instructions V 1.00 Document: V 1.00 / Document No.: 105728 │ Date 28.05.2018
│7
3 Description of the charging station
3.1 Front view
Fig. 1: Overview of charging station
[1]
Housing cover
[2a]
RFID reader (optional)
[2b]
Key operated switch (optional)
[3]
LED bar
[4a]
Permanently installed charging cable
(optional)
[4b]
Charging socket with cover (optional)
[5]
Holder for charging cable (optional)
[6]
Display (optional)
Information
Depending on the design of the charging station, the charging socket or
charging cable may deviate from the shape shown.
