7 Error diagnosis
Error
Possible causes
Remedy
LED bar does not light up
No supply voltage
Check the RCD and line cir- cuit
breaker and switch on if necessary
The charging station is defec- tive
Contact your service partner
Charging process is not
started
The charging cable is not plugged
in correctly
Unplug the charging cable and plug
it in again
The charging process was not
carried out correctly
Follow the instructions in "Charging
process"
The charging socket may be dirty or
damaged in the lock- ing area
Clean the charging socket or have it
replaced
The vehicle does not require energy
or it has an error
Check the vehicle
The vehicle is programmed to
charge at a later starting time
-
No enable due to external control
device (energy sup- plier,
photovoltaic system, ...)
-
The vehicle not fully
charged / longer charging
time
Electricity reduction or inter- ruption
of charging by vehicle or charging
station due to high temperature
When the charging station has
cooled down, the charg- ing
process is continued and the
charging current may be increased
again.
Protect the vehicle and the charging
station from direct sunlight during
the charging procedure (carport,
garage, ...).
-
Visual inspection of the charging
socket to see if it is dirty, worn or
damaged
-
Contact your service partner, if
necessary
Charging cable cannot be
un- plugged
Charging process was not
completed by the vehicle
Complete the charging process
according to the in- structions of the
vehicle man- ufacturer
The charging socket may not unlock
due to tension on the charging
cable
Press the plug in and con- nect
again to the vehicle. Then finish the
charging process again.
LED bar flashes red
Error
Errors must always be ac-
knowledged by unplugging the
charging cable. For more
information, see "FAQs" on the ABB
website.
-
Switch off the supply voltage of the
charging station (in- stalled or
superordinate RCD and line circuit
breaker). Un- plug the charging
cable from the vehicle and the
charging station. Switch on the
voltage supply again.
The charging station is defec- tive
Contact your service partner
