ABB FEPL-02 Ethernet POWERLINK User Manual

136 Appendix C – IdentResponse Frame
NMT Service Slot structure of IdentResponse
Octet offset Bit offset
76543210
0 res res res res res res res res
1PRRS
2 NMTStatus
3Reserved
4EPLVersion
5Reserved
6…9 FeatureFlags
10…11 MTU
12…13 PollInSize
14…15 PollOutSize
16…19 ResponseTime
20…21 Reserved
22…25 DeviceType
26…29 VendorID
30…33 ProductCode
34…37 RevisionNumber
38…41 SerialNumber
42…49 VendorSpecificExtension1
50…53 VerifyConfigurationDate
54…57 VerifyConfigurationTime
58…61 ApplicationSwDate
62…65 ApplicationSwTime
66…69 IPAddress
70…73 SubnetMask
74…77 DefaultGateway
78…109 HostName
110…157 VendorSpecificExtension2
