24 Overview of the Ethernet POWERLINK network and the FEPL-02 module
Layout of the FEPL-02 adapter module
No. Description See chapter
1Lock Mechanical installation
2 Mounting screw Mechanical installation
3 Connector X1 to Ethernet
POWERLINK
Electrical installation
4 Connector X2 to Ethernet
POWERLINK
Electrical installation
5 Diagnostic LEDs Diagnostics
6MAC address -
1
2
3
4
5
6
