44 Start-up
5103 FB PAR 3
(NODE ID)
3
2)
Defines the address of the
device.
3018 COMM FAULT
FUNC
1 = FAULT
2)
Enables fieldbus communication
fault monitoring.
3019 COMM FAULT
TIME
3.0 s
2)
Defines the fieldbus
communication break supervision
time.
5127 FBA PAR
REFRESH
1 = REFRESH Validates the FEPL configuration
parameter settings.
9904 MOTOR CTRL
MODE
2 = VECTOR: TORQ Selects the vector control mode
as the motor control mode.
1001 EXT1
COMMANDS
10 = COMM Selects the fieldbus interface as
the source of the start and stop
commands for external control
location 1.
1002 EXT2
COMMANDS
10 = COMM Selects the fieldbus interface as
the source of the start and stop
commands for external control
location 2.
1102 EXT1/EXT2 SEL 8 = COMM Enables external control location
1/2 selection through the fieldbus.
1103 REF1 SELECT 8 = COMM Selects the fieldbus reference 1
as the source of the speed
reference.
1106 REF2 SELECT 8 = COMM Selects the fieldbus reference 2
as the source of the torque
reference.
1601 RUN ENABLE 7 = COMM Selects the fieldbus interface as
the source for the inverted Run
enable signal (Run disable).
1604 FAULT RESET
SEL
8 = COMM Selects the fieldbus interface as
the source for the fault reset
signal.
1) Read-only or automatically detected/set
2) Example
Drive parameter Setting for ACS355
drives
Description
