Commissioning
FCA/S 1.x.x.1 | 2CDC508134D0202 177
Internal connection
Options:
No
Output E
Output F
Output G
Output H
With this parameter, a direct connection of the binary input with an output can be established. With
this connection, no assignment of the group address is necessary.
 Output E...H: The communication object Switch of the output is updated together with the
communication object Switch 1 of the input.
Attention
If an internal connection with an output is selected, and at the same time the reaction to an event
is parameterized with toggle, the communication object Switch 1 of the input is updated with the
inverted value of the communication object Status Switch of the output.
Ensure that the communication object Status Switch of the output is enabled. The settings
normally closed contact/normally open contact and Invert status should be parameterized, so
that a toggle function is possible.
