Calendar, simple (CALENDAR_S)
Simple comparison of a start time and an end time.
Triggers daily events (for the whole day or at specific times).
The output value is 1 if the device time is between Start and End and the other conditions are met.
Inputs
No.
DPT
Abbr.
Name
Visible
Description
1
Time
S
Start
Parametrizable
2
Time
E
End
Parametrizable
3 1 bit A Active Parametrizable
Value 0 disables the
element, the output
remains unchanged
4
1 bit
GT
Whole time
Parametrizable
Output is always 1
Outputs
No.
DPT
Abbr.
Name
Visible
Description
1
1 bit
A
Output
Always
Parameters
Name
Value
Visible
As input*
Start
Time (hh:mm:ss)
Default = 00:00:00
Always Yes
End
Time (hh:mm:ss)
Default = 00:00:00
Always Yes
Active
Checkbox
Always
Yes
Whole time
Checkbox
Always
Yes
* As input = if yes: parameter is input.
