7.5.5 BACnet objects
The ASM can only ever transmit/receive one value and therefore has only one BACnet object. Depending
on the template selected, this is an input or output.
The data point type is also dependent on the parameterization of the ASM.
Type
Object name
Object type
Unit
COV send
condition
Input
Value: Value
Configuration-
dependent
Configuration-
dependent
-
Output Value: Value Configuration-
dependent
Configuration-
dependent
1.0
BACnet input objects
Object name
Object type
Unit
COV send
condition
Value: Value
Configuration-
dependent
Configuration-
dependent
-
The module has a BACnet input object if the KNX to BACnet template or the Freely configurable template is selected with the
BACnet: Readable by BACnet parameter.
Input for the BACnet value for output on the parameterized interfaces.
Signal value:
Configuration-dependent
BACnet output objects
Object name Object type Unit COV send
condition
Value: Value Configuration-
dependent
Configuration-
dependent
1.0
The module has a BACnet output object if the
BACnet to KNX
,
BACnet to KNX with update
template or the
Freely configurable
template is selected with the parameter BACnet: Read + writable by BACnet .
The current value from the parameterized interfaces is output via this object on BACnet.
Signal value: Configuration-dependent
