ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 155
BACnet to KNX
A value received via the BACnet object is sent by the group object using this template. A value received
from the KNX bus is not transmitted back to the BACnet object. The value is also output on the web user
interface and on the ASM output socket for linking to other modules.
The settings for the ASM socket, web user interface, KNX and BACnet are set automatically as follows:
ASM socket:
Output
WebUI:
Display
KNX:
Output to KNX
BACnet:
Read + writable by BACnet
Main data point type
Data point type
Definition of the data point type that is transferred between the interfaces.
You will find further information on the data point types in chapter 4.7 Data point types
.
Use value after restart
Options:
Last value
Initial value
This parameter defines which value is output in the group object and the ASM output socket after starting
the application controller until a new value is entered on the web user interface.
• Last value: The last value before device start is saved and reused. The value parameterized further
down in Initial value is used after the first download of the module to the application controller.
• Initial value: The value described further down in Initial value is used.
