ABB i-bus
®
KNX
Commissioning
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 45
6.5.2 ASM library
All application-specific automation modules (ASM) available for the device are displayed in this section.
From there the ASM can be dragged to the workspace (drag & drop) for parameterization. As an
alternative, a double-click adds the selected ASM to the Standard workspace.
The help texts and the standard parameters for the ASM selected in the ASM library are displayed in the
ASM property bar for information.
Click to minimize and maximize the ASM library.
6.5.3 Structure
To structure the project (e.g. parts of the building, parts of the system, …) you can add containers by
clicking the symbol. The containers are displayed in the workspace; the ASMs are added to the
containers using drag & drop.
Containers can be nested one inside the other. The web user interface with the navigation menu is
generated automatically from the container structure created.
If you delete a container using the symbol, you will also delete the ASMs it contains.
The Standard container can only be renamed, but not deleted.
