ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
276 2CDC508198D0211 Rev. A | AC/S 1.x.1
7.9.5 BACnet objects
Type
Object name
Object type
Unit
COV send
condition
Input Heating distribution circuit: Supply setpoint temperature External
specification
Analog value °C (62) -
Output Heating distribution circuit: Return temperature Analog value °C (62) 1.0
Output Heating distribution circuit: Supply temperature Analog value °C (62) 1.0
Output Heating distribution circuit: Supply setpoint temperature status Analog value °C (62) 1.0
Output Heating distribution circuit: Outside temperature Analog value °C (62) 1.0
Output
Heating distribution circuit: Supply setpoint temperature override
status
Binary value
-
-
Output Heating distribution circuit: Supply setpoint temperature External
specification
Analog value °C (62) 1.0
Output Heating distribution circuit: Operation mode Positive integer
value
No unit
(95)
1.0
Output
Heating distribution circuit: Room setpoint temperature Comfort
Analog value
°C (62)
1.0
Output
Heating distribution circuit: Room setpoint temperature Standby
Analog value
°C (62)
1.0
Output Heating distribution circuit: Room setpoint temperature Economy Analog value °C (62) 1.0
Output Heating distribution circuit: Room setpoint temperature Building
Protection
Analog value °C (62) 1.0
Output
Heating distribution circuit: Max. room setpoint temperature
Analog value
°C (62)
1.0
Output
Heating distribution circuit: Control On/Off
Binary value
-
-
Output Heating distribution circuit: Room involvement Analog value °C (62) 1.0
Output Heating distribution circuit: Control On/Off override disable/enable Binary value - -
Output Heating distribution circuit: Room control values Analog value % (98) 1.0
Output
Heating distribution circuit: Pump A override disable/enable
Binary value
-
-
Output
Heating distribution circuit: Pump A override value
Binary value
-
-
Output
Heating distribution circuit: Pump A operating status (Off/On)
Binary value
-
-
Output
Heating distribution circuit: Pump A relay status
Binary value
-
-
Output Heating distribution circuit: Pump A fault Binary value - -
Output Heating distribution circuit: Pump A repair switch status Binary value - -
Output Heating distribution circuit: Pump B override disable/enable Binary value - -
Output Heating distribution circuit: Pump B override value Binary value - -
Output Heating distribution circuit: Pump B operating status (Off/On) Binary value - -
Output
Heating distribution circuit: Pump B relay status
Binary value
-
-
Output
Heating distribution circuit: Pump B fault
Binary value
-
-
Output
Heating distribution circuit: Pump B repair switch status
Binary value
-
-
Output
Heating distribution circuit: Valve control value
Analog value
% (98)
1.0
Output Heating distribution circuit: Valve override disable/enable Binary value - -
Output Heating distribution circuit: Valve override control value Analog value % (98) 1.0
Output Heating distribution circuit: Status Valve purge Binary value - -
