Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 115
Parameters
The Time section specifies the time of day when the output has the value 1. At all other times the output
has the value 0.
The Recurrence section specifies the days on which the element is active. On these days the output has
the value 1. On all other days the output has the value 0.
Note
Recurrence Every ... day(s), Every ... week(s) on, Day ... of every ... month(s), Every ... year(s) starts on
the date set in the Duration section.
The Duration section specifies the dates between which the element is active.
All the parameters can also be set via inputs. Selecting the corresponding As input checkbox activates the
inputs.
Time section parameters
Parameter name
Value
Description
Start
Time of day in minutes, default = 00:00:00
Sets the start time
End
Time of day in minutes, default = 00:00:00
Sets the end time
Whole time
1 bit, default = false (0)
Sets a whole time
Active 1 bit, default = false (0)
Activates/deactivates the
element
