Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 169
• Or: The input values are combined using a logical OR operator.
Value 1
Value 2
Value used
0
0
0
1
0
1
0
1
1
1
1
1
• And: The input values are combined using a logical AND operator.
Value 1
Value 2
Value used
0
0
0
1
0
0
0
1
0
1
1
1
WebUI
Options:
Display
Display + Set
(not available if the Input option has been selected for ASM socket)
Possible settings for the web user interface.
• Display: The value from the other interfaces is displayed on the web user interface and cannot be
changed.
• Display + Set: The value is displayed on the web user interface and can be changed.
